Power Conditioner

PLIXIR Power Conditioner ELITE for perfect power supply.

The PLiXiR BAC is designed and built with our PureTone sound quality concept in mind.
Absolutely neutral, naturally low noise.

As such, the BAC does not employ any protection circuits detrimental to sound quality, like surge
protection MOV, current limiting magnetic switches etc. There are also no voltage regulation,
stabilization or regeneration circuits within our BAC.
In particular there are no Capacitor and inductor filters within our BAC for noise filtration.

Based on the best balanced power transformer made to our exact design and specifications, it will provide you with years of trouble free operation if you use them within their operating specifications.

Once the BAC is powered on, you can always leave it on. On its own, its power consumption is less
than 5Watt and do not generate much heat. Indeed, we would like the BAC to be kept on, for the voltage to be maintained so that the dielectric in the copper wiring and the transformer is always charged up for the best sound quality.

To achieve true balanced transformer winding, PLIXIR partner with premier transformer-maker Noratel to custom-produce our balanced transformers based on their cutting-edge XQ eXtra Quiet noise attenuation technology.

            BAC 1500 hinten flach

Selection of PLiXiR BAC:
For optimal audio transient and dynamics performance it is important to over-rate your actual power usage by at least 50% (x1.5). Very often, 100% (x2) is better.
This is particularly important for power amplifiers. For example, if your system’s total system power maximum (source + power amplifier) is 1000W (from the user manual of your equipment), the minimum supply should be 1500W.



PLIXIR Elite BAC 150

PLIXIR Elite BAC 150

Application:

  • Desk-fi setup including a DAC, head amplifier and a pair of small sized active speakers (example ADAM’s Artist 3).
  • hi-fi source equipment: Pre-Amp, DAC, Transport, CD/BD Player, media server, turntable etc.
  • Mac mini style media server PC/Laptop together with your audio equipment.
  • hi-fi system power conditioner for stereo amplifier system not more than 20W Class A or 50W Class AB per channel, along with the CD Player/ Preamp/DAC



Specification

  • Number of outputs: 2
  • Input 220~240 Vac to output 220~240 Vac balanced 50hz
  • No load idle power consumption: less than 5W
  • Casing finish: Black anodized
  • Power Output: 150W Max
  • Weight: 4.5kg
  • Dimensions (in mm): 230 x 160 x 70#



Price 599,- €

Price incl. VAT, plus shipping costs








PLIXIR Elite BAC 400

PLIXIR Elite BAC 150

Application:

  • Desk-fi setup including a DAC, head amplifier and a pair of small sized active speakers (example ADAM’s Artist 3).
  • hi-fi source equipment: Pre-Amp, DAC, Transport, CD/BD Player, media server, turntable etc).
  • Mac mini style media server PC/Laptop together with your audio equipment.
  • hi-fi system power conditioner for stereo amplifier system not more than 20W Class A or 50W Class AB per channel, along with the CD Player/ Preamp/DAC



Specification

  • Number of outputs: 4
  • Input 220~240 Vac to output 220~240 Vac balanced 50hz
  • No load idle power consumption: less than 5W
  • Casing finish: Black anodized
  • Power Output: 400W Max
  • Weight: 8.6kg
  • Dimension (in mm) : 230 x 160 x 130



Price 1099,- €

Price incl. VAT, plus shipping costs








PLIXIR Elite BAC 1500

PLIXIR Elite BAC 150

Application:

  • Desk-fi setup including a DAC, head amplifier and a pair of small sized active speakers (example ADAM’s Artist 3).
  • hi-fi source equipment: Pre-Amp, DAC, Transport, CD/BD Player, media server, turntable etc.
  • Mac mini style media server PC/Laptop together with your audio equipment.
  • hi-fi system power conditioner for stereo amplifier system not more than 20W Class A or 50W Class AB per channel, along with the CD Player/ Preamp/DAC



Specification

  • Number of outputs: 6
  • Two voltage variants: Input 100~120 Vac to output 100~120 Vac balanced 60hz Input 220~240 Vac to output 220~240 Vac balanced 50hz
  • No load idle power consumption: less than 5W
  • Casing finish: Black anodized
  • Power Output: 150W Max
  • Weight: 24kg
  • Dimensions (in mm): 288 x 285 x 142



Price 2799,- €

Price incl. VAT, plus shipping costs

PLIXIR Elite BAC 3000 - 3000V

PLIXIR Elite BAC 3000V
There is no translation available.

Anwendung:

  • Vollverstärker und Vorverstärker mit weniger als 240W Class A oder 600W Class AB pro Kanal an 4 Ohm, zusammen mit CD-Player, DAC etc.
  • Kleingeräte: DAC, Kopfhörerverstärker, Phonoverstärker und kleine Aktivlautsprecher
  • Quellgeräte: CD-Player, Media-Server, Plattenspieler etc.
  • Mac mini Media server PC/Laptop zusammen mit Audio Equipment


Spezifikation:

  • Ausgangsleistung (RMS): 2000W
  • Max. Belastbarkeit kurzzeitig: 3000W
  • Anzahl Ausgänge:
    3000    8 Ausgänge
    3000V  6 Ausgänge
  • Eingang:  220~240 V Wechselspannung
  • Ausgang: 220~240 V Wechselspannung balanced 50hz
  • Dauerhafter Spitzenstrom 13A
  • Stromverbrauch im Leerlauf: weniger als 5W
  • Farbe: Schwarz oder Aluminium
  • Gewicht
    3000:    37 kg
    3000V:  44 kg

  • Maße (BxTxH in mm):
    3000:     80 x 140 x 350 (390mm mit Griffe)
    3000V:  150/250 x 380 x 345 - Breite ohne Sockel 150mm, mit Sockel 250mm

  • Frage: Schwarz oder Aluminium sandgestrahlt

Das dazu passendes Netzkabel bPower finden Sie hier

Elite BAC 3000   (horizontal)   Preis 3999,- €   (siehe letztes Foto)
Elite BAC 3000V
(vertikal)       Preis 4499,- €

Preis inkl. MwSt., zzgl. Versand

zum Online-Shop

Bei Interesse kontaktieren sie uns: info@bfly-audio.de
